Introduction to Friction Fire Lighting: Bow Drills and Hand Drills



The history of friction fire lighting is bound up with the history of human civilization. The ability to light a fire when needed provides security, warmth, the ability to cook food and many other tenements of human civilization. The ability to light a fire by friction is a cornerstone of bushcraft and a key part of our weekend bushcraft course .  This blog provides an overview of friction fire lighting and an introduction to getting started.



friction fire lighting with W

A short history of friction fire lighting

The ability of humans to make and control fire was a huge turning point in human history. There is evidence that humans were able to control fire from about 1.7 million years ago. This control of fire would have most likely been around wildfires.

Learn the art of friction fire lighting on our weekend bushcraft course.

Making fire

The ability to make fire, as opposed to controlling naturally occurring fires, was thought to have occurred about 700,000 years ago. It allowed humans to change their locations, provided security, warmth and lead to massive changes in diet.  The ways in which people made fire was through friction, using devices such as the hand drill or fire plough.



Impact on human evolution

The impact of fire on human evolution is enormous. It allowed people to migrate to cooler climates as they were now more able to survive the cold winters. The ability to make fire also provided protection from animals and, it is argued, helped humans to clear out caves prior to living in them. The ability to fire also played a key part in tools and weapon making, as well as ceremonial occurrences and art.



An introduction to friction fire lighting

Friction fire lighting is a large and complex topic. The ability to make fire by friction is not something that can be learned quickly or even mastered. Rather it is a lifetime of learning and honing skills. Like anything in bushcraft, the ability to make fire by friction begins with understanding materials.

Learn the art of friction fire lighting on our weekend bushcraft course.

Understanding materials



Bushcraft in Dorset using a bow drill



Being able to identify trees, plants, fungi, animals, etc is the cornerstone of bushcraft. Without the ability to identify the best material for the task in hand, you are unlikely to be successful.

Suitable woods for the bow drill/hand drill

The following are the most suitable woods for the bow drill and hand drill. For the sake of simplicity and relevance, we are only focusing on European woods.  Keep in mind that this is not an exhaustive list!

Woods for bow drill

  • Elder
  • Field Maple
  • Willow
  • Hazel
  • Oak
  • Popular
  • Yew
  • Sycamore
  • Ivy

Woods for hand drill

  • Elder
  • Juniper
  • Pussy Willow
  • Sycamore

Learn more about choosing woods for the bow drill and hand drill in our blog:
Choosing Wood For a Bow Drill



Bow Drill

The bow drill is perhaps the best-known friction fire lighting tool. It is thought to date back as far as the 4th or 5th millennium. They were used by cultures around the world including Native Americans, Eskimos, and Aborigines in Alaska and Canada

The bow drill has one massive advantage over other friction fire lighting methods – it’s mechanical nature; that is, the drill is turned by a cord, not by the user’s hands.

Learn the art of friction fire lighting on our weekend bushcraft course.



Making your bow drill

A bow drill works in the same manner as all other friction fire lighting methods. That is two combustible materials being rubbed together until the material is taken beyond its auto-ignition temperature which creates an ember. This ember is then used to ignite tinder.

Component parts of the bow drill

The image below shows the component parts of the bow drill – the bearing block, bow, drill and hearth. We will then look at each of these parts in detail.

https://www.wildwaybushcraft.co.uk/product/one-day-friction-fire-lighting-course/

The different parts of the bow drill.

The Bow

The bow for your bow drill can be made of any wood that you have to hand. As the name suggests it needs to be slightly curved and should be the length from about your fingertips to your sternum.

The Drill

The drill should be around 20cm in length and between 2 -3cm.  The wood for the drill should be made of one of the woods identified earlier in the blog. The end of the drill in contact with the hearth should be carved into a blunt point, while the end that is in contact with the bearing block should be carved into a sharper point.

The Hearth

The hearth of a bow drill should be made of one of the woods identified previously. It does not need to be made of the same material as the drill. It helps to play around and find the combination of woods that works the best for you. Ivy and Hazel are two types of wood that we particularly enjoy using. The hearth needs to be carved into a rectangle about 4cm wide and 5mm thick. Narrow a depression into the hearth in the centre of the blog then, using the bow, wear down this depression into a smooth bore then cut a V shape extending towards and over the edge of the hearth.

The Bearing Block

The bearing block can be made of any wood that you have to hand. It should fit comfortably in your palm. You will need to carve a notch into the bearing block for the sharper end of the drill to sit in.

Learn the art of friction fire lighting on our weekend bushcraft course.

bow drill being used in the woods

Hand drill

The hand drill works on the same principles as the bow drill, although it lacks the mechanical advantage. The drill is composed of a drill and a hearth. It works as the drill is spun between your hands and is spun with downward pressure being applied. As the smoke begins to appear, increase the speed until you have produced a small ember.

fire lighting Dorset

The Drill

The drill for the hand drill is largely a matter of personal preference, experience and what type of wood you are using. It should be made of one of the woods identified previously and be between 40 and 75 cm long with a diameter of 9mm to 13mm. It needs to be as straight as possible to work effectively.



The hearth

The hearth should be made in a similar fashion to the bow drill but slightly shorter. Once again, it should be made of the same wood as those mentioned previously in the blog.

Friction fire lighting on our weekend bushcraft course

On our weekend bushcraft course we introduce you to the art of the bow drill. If you have never used a bow drill before, we will talk you through how to carve each of the component parts and how to correctly use it. If you are familiar with the bow drill then we can help you to troubleshoot any issues that you are having and give you tips on how to perfect your bow drill technique.

Learn the art of friction fire lighting on our weekend bushcraft course.



Wildway Bushcraft Owner John blowing an ember into fire
